FX Luminaire PB 3LED Wall Wash in Flat Black, Zone w/ Luxor | PB3LEDFB

Name: FX Luminaire PB 3LED Wall Wash in Flat Black, Zone w/ Luxor | PB3LEDFB
Brand: FX Luminaire
SKU: L-FXL-PB3LEDFB
Price: 191.99 USD
Availability: InStock

FX Luminaire PB 3LED Wall Wash in Flat Black, Zone w/ Luxor | PB3LEDFB

Wall Wash Uplight

Quantity

$191.99

~~$261.30~~ $191.99

Sale Sold out

Shipping calculated at checkout.

The PB series of fixtures are compact and durable LED wall wash lights designed to illuminate larger structures and spaces with a broad, uniform light. Despite its small size, its wide-angle beam and powerful output make it an ideal choice for a variety of applications.
Comes with a tempered frosted glass lens with shock resistance and high tolerance for thermal expansion and stress.

Key Features of the PB Series of Wall Wash Fixtures from FX:

Warm white 2700k, 265lm, 4W, 4.4VA, 3LED, 84 CRI & a 72,000 hour Lamp Life.
Zone with Luxor, and Phase Dimmable

Includes fixture, specified LED board (1), 10' (3 m) lead wire*, lock ring (1), and spike (1).
Powerful Illumination: A wide-angle beam allows you to light larger surfaces and structures, making it versatile for many applications.
Durable Construction: Built with a solid die-cast aluminum or brass body to withstand the elements.
Integrated Technology: Features integrated Lumileds® LEDs and ProAim™ adjustability for precise aiming.
Multiple Options: Available in one or three LED configurations, including ZDC options, to suit your specific lighting needs.
Low Voltage: Operates on a safe 10-15V input voltage.

Product Specifications
Bulb/Lamp:	Integrated LED
Watts:	4W
Color Temp:	2700K
Lamp Life:	72,000 hrs
Optimal Voltage:	12V
Beam Spread:	90 VWF
Lumens:	265lm
CRI:	84
Product Model:	PB3LEDFB
Color/Finish:	Flat Black
Manufacturer:	FX Luminaire

View full details

FX Luminaire Landscape Lighting Integrated Fixtures

What does integrated mean?

Simply put: It means the light source is not an easy to replace light bulb. However with many FX Luminaire fixtures, there IS a board that is replaceable! Always double check literature from the manufacture before purchasing to know if the fixture contains these boards.

Here a few basic type of integrated options offered by FX Luminaire:

1LED, 3LED, 6LED or 9LED Options (Standard / Fixed CCT) - Delivers efficient, focused illumination with a fixed color temperature (such as 2700K or 3900K) and field-changeable optical lenses.

Best For: Standard landscape lighting layouts requiring reliable, high-efficiency accent or pathway lighting without complex digital grouping requirements.

ZD Option (Zoning & Dimming) - Fully compatible with the Luxor digital control system to provide wireless zoning and dimming capabilities.
Group fixtures into up to 250 unique zones and adjust brightness smoothly in 1% increments (0–100%) directly from the controller.

ZDC Option (Zoning, Dimming, & Color) -
Advanced RGBW board offering complete architectural lighting control with 30,000 custom color combinations.
Seamlessly integrates zoning, dimming, and live color customization for holiday themes, seasonal accents, and dynamic architectural highlights.
